High Load Capacity ATLAS-RB 315 Wheel Block System

The ATLAS-RB315 Wheel Block System is a high-performance traveling wheel block system designed for heavy-duty processing applications. The following is a detailed analysis of the ATLAS-RB315 wheel block system:

Characteristic

 1. High load capacity: The maximum wheel load of the ATLAS-RB 315 travelling wheel block can reach 22,000 kg.

 2. Diverse design: Available in a variety of forms, including double-sided flange (Form 1), single-sided flanges (Form 2 and 3), no flanges and cylindrical running surfaces (Form 4), without flange and spherical running surfaces (Form 5), etc.
 3. Material options: Standard models include PA 12G coating (Form 6) and Vulkollan® polyurethane coating (Form 8), and special models include specially designed Vulkollan coating (Form 8S).
 4. Easy maintenance: Designed for low maintenance, such as the use of self-lubricating roller bearings for life, reducing maintenance requirements.

Installation

 1. Top connection: Precise installation using locking screws, suitable for connection construction with precise drilling, no wheel box adjustment required.
 2. Pin connections: Adjustable pin connections are available for installation of hollow profiles, floating levers, etc., aligned by adjusting washers.
 3. Precise fit or adjustable direct connection: as a bolt connection, suitable for welded structures, rolled parts, etc.

Accessories

 1. Locking screw: for top connection, specification M16×45, tightening torque of 330 Nm.
 2. Locking pin: Used for top connection, 18.5×1×14.
 3. Bolts and washers: For pin connections, bolts, washers and adjusting washers are available in different lengths and specifications.

Application

 1. Crane machinery: Suitable for the crane wheel box, to provide stable load and movement capacity.

 2. Conveyor systems: In conveyor belt related systems, as a solution for multi-purpose transport requirements.
 3. Heavy machinery: In the whole field of machinery manufacturing, to meet the diverse transportation needs.

The ATLAS-RB 315 wheel block system occupies a place in the industrial wheel box market with its high load capacity, diversified design, flexible installation mode, rich accessory selection and wide application fieldATLAS-RB315 wheel block system.
