Parts and features of ATLAS-RB 125mm Travel Wheel System

The travel wheel system is a key component in the crane travel mechanism that carries weight and supports the entire structure. The travel wheel blocks system is divided into two types: suspension wheel and travel wheel. The travel wheel system is a critical component of the crane's travel mechanism, which carries weight and supports the entire structure. The travel wheel block system is categorized into two types: suspension wheels and travel wheels.The former is used to carry and support the static load of the entire crane, while the latter is responsible for bearing dynamic loads during travel, and also plays a role in guiding, positioning and shock absorption. The wheel block system has a high-strength steel shell and a hardened surface to enhance its wear resistance and load-bearing capacity. The wheel can be made of polyurethane, peek, or metal.

Features of DRS Wheel Blocks

The fully enclosed design of DRSA Wheel Block System: with high tensile strength, overall firmness and wear resistance, its design service life is up to 10 years

Large load capacity of a single modular wheel block: 1ATLAS-RB 125 load capacity：11000lb,5000kg

The diameter of the wheel box series ranges from 112 mm to 500 mm and customizable load capacity from 2.75 to 40t

Wheels made of polyurethane or peek: light travel sound, wear resistance, temperature resistance, sealing, sound insulation, and good processing performance

Drive wheel spline hub: spline connection with motor, compact structure and reasonable design

Five finished surfaces: convenient connection with different structures to ensure accurate installation

Modular standard design: a full set of travel solutions and components, greatly simplifying the cost and time of customer travel mechanism design

Bearings: NSK bearings are used for long service life

MAILUN POLYURETHANE is a Polyurethane Wheel Blocks Supplier, and its products include KARL GEORG wheel sets, wheel sets, polyurethane drive wheels, PEEK wheels, travel wheel accessories, non-standard customized crane wheels, etc. If you have special customization needs, please contact us at any time
